Electromechanical control panel.
1 washing cycle of 120".
Tank capacity: 15 l. / Heating power: 2.0 kw.
Boiler capacity: 5 l. / Heating power: 2.8 kw.
Wash pump power: 0.3 kw.
Rinsing consumption: 2.5 l/rinse.
Upper and lower washing and rinsing arms.
Independent cycle for cold rinsing.
Built-in rinse aid dispenser.
Anti-backflow valve fitted.
Safety thermostat in washing tank and boiler.
Temperature adjustement: Wash 60 ºC and rinse 85 ºC.
Supply voltage: 230V / 1N 50 Hz.
Accessories supplied: 2 baskets of 400 x 400 mm, 1 dish bracket and 1 basket for cutlery CU.
OPTIONAL MODELS WITH
- Built in detergent aid dispenser.
- Built in draining pump.
- Stainless-steel washing and rinsing arms.
- UK version. With 2.4 kW boiler heating power and UK plug (13A).
- 60 Hz version.

Model	Reference	Baskets/hour	Door clearance (mm)	Dimensions (mm)	Detergent dispenser	Drain pump	Power (kW)	Voltage (V)
GE-400	19042299	30	270	470x525x720	No	No	3.05	230 V/ 1N 50 Hz
GE-400 DD	19047937	30	270	470x525x720	Yes	No	3.05	230V-50Hz
GE-400 B	19059572	30	270	470x525x720	No	Yes	3.05	230V-50Hz
GE-400 B DD	19059573	30	270	470x525x720	Yes	Yes	3.05	230V-50Hz
