Electronic control panel.
3 washing cycle of 90” / 120" / 180”
Tank capacity: 15 l. / Heating power: 2.0 kw.
Boiler capacity: 5 l. / Heating power: 2.8 kw.
Wash pump power: 0.3 kw.
Rinsing consumption: 2.5 l/rinse.
Upper and lower washing and rinsing arms.
Thermostop function.
Soft washing start.
Independent cycle for cold rinsing.
Built-in rinse aid dispenser.
Anti-backflow valve fitted.
Safety thermostat in washing tank and boiler.
Temperature adjustement: Wash 60 ºC and rinse 85 ºC.
Supply voltage: 230V / 1N 50/60Hz.
Accessories supplied: 2 baskets of 400 x 400 mm, 1 dish bracket and 1 basket for cutlery CU.
OPTIONAL MODELS WITH
- Built in detergent aid dispenser.
- Built in draining pump.
- Stainless-steel washing and rinsing arms.
- UK version. With 2.4 kW boiler heating power and UK plug (13A).

Model	Reference	Baskets/hour	Door clearance (mm)	Dimensions (mm)	Detergent dispenser	Drain pump	Power (kW)	Voltage (V)
GM-400	19067324	40	270	470 x 530 x 725	No	No	3,05	230V-50/60Hz
GM-400 DD	19068327	30	270	470x525x720	Yes	No	3,05	230V-50/60Hz
GM-400 B	19068328	30	270	470x525x720	No	Yes	3,05	230V-50/60Hz
GM-400 B DD	19068329	30	270	470x525x720	Yes	Yes	3,05	230V-50/60Hz
